| Exploring Inner Space

NUANCE: Nanoscale Characterization Experimental Center

The 2025 'Art of Science Image Contest' is coming soon! Get your images ready - submission portal opens August 4, 2025!

"Sunflower Bouquet" Image by Kira Fahy, Farha Group; Instrument: JEOL 7900-FLV

Facilities

Events

Upcoming Events

Jul
25
2025
Advanced TEM characterizations of battery and catalytic materials

10:30 AM - 11:30 AM, Cook Hall, 2220 Campus Drive

Dr. See Wee Chee "Combining Microscopes: Correlative Operando Spectro-Microscopy as a Bridge between Microscopy and Spec...

Aug
21
2025
NUANCE Tech Talk: EPIC FIB

11:00 AM - 12:00 PM

Please join us for monthly user meetings! Tech staff will showcase our state-of-the-art capabilities, provide updates on...

Sep
19
2025
NUANCE Tech Talk: SPID

11:00 AM - 12:00 PM

Please join us for monthly user meetings! Tech staff will showcase our state-of-the-art capabilities, provide updates on...

Instrument Spotlight

New JEOL JIB 4700F now at NUFAB!

samco drie
The JEOL JIB-4700F is a high-resolution SEM with EDS and FIB
3 Detectors
  • Secondary Electron Detection -- Lower, Upper, and FIB imaging.
  • Backscattered Electron Detection -- Composite and Topographical imaging
  • Energy Dispersive Spectroscopy
  • Combination of detector signals is possible.
Read about all the features of the JEOL JIB 4700F!

Learn more

Contact:
Nathan Dvorak, PhD

NUFAB Postdoctoral Scholar, NUANCE Center

Office:
Tech #FG71
Email:
nathan@northwestern.edu
Phone:
(847) 467-0147
